FLIR 14° Lens (f =29 mm) with Case

The FLIR 14° Lens (f = 29 mm) with Case is an interchangeable thermal imaging lens designed to expand the capabilities of compatible FLIR handheld thermal cameras. It gives you a narrower, telescopic field of view so you can see heat details at longer distances or on smaller targets that a standard lens might miss.

Key Features

• 14° × 10° Field of View (FOV): Offers a tighter, more focused thermal image ideal for distant subjects or detailed inspection.
• 29 mm Focal Length: Telephoto setup that magnifies thermal scenes compared to the camera’s standard lens.
• Auto-Calibration (AutoCal): Lens identification and calibration happen automatically once attached to the camera — no manual setup needed.
• Durable Carrying Case Included: Comes with a protective case for transport and storage.

Specifications:

Imaging and optical data

Field of view (FOV): 14° × 10°

Minimum focus distance: 1.0 m (3.28 ft.)

Minimum focus distance with MSX: 1.0 m (3.28 ft.)

Focal length: 29 mm (1.41 in.)

Spatial resolution (IFOV): Dependent on the IR resolution of the camera

• 320 × 240 pixels: 0.75 mrad/pixel

• 464 × 348 pixels: 0.52 mrad/pixel

• 640 × 480 pixels: 0.38 mrad/pixel

Lens identification: Yes, AutoCal

F-number: 1.5

Measurement

Accuracy: ±3°C (±5.4°F) or ±3% of reading, for ambient temperature 15–35°C (59–95°F) and object above

Weight 0.140 kg (0.31 lb.)

Size (L × D) 45.4 × 72 mm (1.79 × 2.83 in.)

What's in the Box:

1 x Telephoto Lens

1 x Protective Carrying Case
